6.antistatic,preventing magnetic strong interference.
Item Name | Model No. | The Type of Touchscreen | Machine Configuration |
55 inch floor stand kiosk | MAD-550F | Optional | Standard |
1,Adopt hardened metal shell,antistatic,preventing magnetic strong
interference.
2, With 3mm thickness tempered glass as protection layer against
the surface of LCD screen.
3,Adopt newest A＋LCD screen,with high contrast ration,high
brightness,last longer and work better.
4,Support SD card or USB port at one player; it is optional for VGA
Port, S-video port and port.
Compatible all formats of high definition video signal and standard
definition video signal input(,YPbPr,
VGA,CVBS*2)and output(AV).
5,Safely locking system function to avoid flash memory card and
advertising playing contents being taken
away, also can be protected by password.
6, With USB update feature; support functions between the card and
card copying files (such as CF card to
SD card,or SD to CF card etc.); support U-copy, conveniently and
quickly updating target content, more
details please visit user manual.
7,Playing advertising program automatically and circular; support
media format: JPEG (JPG), MP3, AVI,
MPEG1, MPEG2, MPEG4, VOB and DIVX (5.0/6.0).
8,Playlists support functions, can set different folders, copy all
target files to those different folders, system
would default to play your target file one by one.
9,Capable of setting rolling caption on the screen, playing rolling
caption in the advertisement program.
10,Build-in clock and calendar function in the system of player.
11,Automatically turn up or down the volume of ad media player
after finished the period of time setup to
machine according to your requirements.Support 5 groups of auto
power-on/off timer, able to set those
5 groups of time one day and 7 days in one week.
12,Support 1080P Full HD Video and picture.
13,with scrolling marquee and angle icon display for any interval
and segment quantity.
14,Automatic restart and shutdown periodically.
15,Support playlist function and slides showing automatically.
16,Adopt an external power adapter to supply power,more safe and
reliable.
17,Automatic recognize PAL/NTSC video display.
18,Support key operation and IR remote control.
19,Physical resolution up to 1920*1080,compatible below
resolution.automatically adjust to the best place.
20,The scientific Golden Angle Design is adopted for the body,
super-thin and light machine body.
● General Specification |
Model No. | MAD-550F |
The material of machine body | Aluminium profile,3MMtoughened glass |
Certification | CCC,RoHS,CE |
Interface | USB |
Guarantee | 1 year |
Speaker | 10Wx2 |
Storage Medium | Flash memory card(2gb to 36gb for the capacity) |
Video formats | MP4(AVI:DIVX/XVID),MPG2(DVD:VOB/MPG2), MPEG1 (VCD: DAT/MPG1) |
Audio formats | MP3 |
Photo formats | JPG,bmp |
Audio output | stereo L/R, 5W*2, 8Ω |
Storage Temp. | -7 to 65 Celsius degree |
Normal Working Temp. | -5 to 65 Celsius degree |
Language | The default is Chinese and English,others need to be confirmed |
Power Supply | AC 110V - 240V, 50/60HZ |
● LCD display specification |
The size of screen | 55 inch |
Ratio | 16:9 |
Display area | 1210mm(H) x 682mm(V) |
Dot Pitch | 0.63mm(H) x 0.63mm(W) |
Max Resolution | 1920 X 1080 |
Number of colors | 16.7M |
Brightness | 500cd/㎡ |
Response Time | 8s |
Contrast | 1500:１ |
Viewing angle | 89°/89°/89°/89°(Min.)(CR≥10)(L/R/U/D) |
Using Life | 50000 hours |
● Accessory |
Standard accessory | AC power line |
Remote Controller |
Base |
Warranty card |
Flash memory card |
Security Keys |
User Manual |
● Applications |
E-communication | Can show promotional information or charge list in the hall of Communication operators etc. |
Finance & Securities | Can send the special,information (images and videos) in all kinds
of sales network spot etc. |
Transportation | Can show the local traveling information,lodging information in
Airport, station,or wharf etc. |
Real Estate | Can transfer some houses information,promotion or sales information of land agent in building selling center or Community etc;urge the property fee etc. |
Hotels | Can show some service information,general situation of local place
in the hall of hotels etc. |
Residential&commercial buildings | Can show some special,company advertisement or local situation in
the exit or entrance of the buildings etc. |
Entertainment&fitness | Can add some promotional ads or activities of nightclub.dance hall, singing hall,entertainment center,fitness centers,Health Club,tea
house and amusement park etc. |
Mall | Can recommend hot selling products,promotional ads,special merchant in mall or supermarket. |
Culinary culture | Can recommend popular dishes,special dishes of restaurant or chain eating house etc. |
Cultural sites | Can show ads in theatre,Science Museum,Cultural Center, library,cinema etc. |
Medical Institutions | Can show ads or medical guide or information of specialist in
hospital, rehabilitation centre etc. |
Auto industry | Can show some special service,discounted products,local
introduction in 4S store or exclusive shop,maintenance station,Motown, Accessories Sale Center etc. |
Scenery spot&Park | Can introduce local information,eating house,news in park or tourist attractions etc. |
