0.44mm Gap TV Lcd Digital Signage Video Wall LG Panel LD550DUN-TMA1 /DVI/BNC Video Monitor

Specification:

The splicing screen is a complete LCD splicing display unit that can be used as a display alone or as a large screen with LCD splicing. According to different usage requirements, the variable large and variable large-screen large-screen functions can be realized: single-screen split display, single-screen separate display, arbitrary combination display, full-screen LCD splicing, vertical screen display, and image frame can be compensated or covered.

Feature

1, long life. With the advancement of science and technology, the service life of liquid crystal products can reach more than 50,000 hours (mainly affected by backlights). At present, the mainstream LED backlight technology in the market has basically got rid of the limitations of the CCFL backlight era, and its service life can be When it reaches 100,000 hours or more, the brightness can reach 1000 lumens, and the light source will not be dark after a long period of use.
2. The perspective is large. For the early LCD products, the viewing angle used to be a big problem that restricts the liquid crystal. However, with the continuous advancement of the liquid crystal technology, this problem has been completely solved, such as the splicing screen using DID and IPS technology, which is visible. The angle can reach an unprecedented 178 degrees.
3. High resolution. According to the current mainstream technology in the market, the physical resolution of the liquid crystal display can easily reach the retina level that cannot be distinguished by the naked eye. The brightness and contrast of the liquid crystal are high, the color is bright and bright, and the image is stable and does not flicker.
4, ultra-thin and light. The liquid crystal has the characteristics of thin thickness and light weight, and can be easily spliced ​​and installed. The 55-inch LCD screen weighs only 30KG and has a thickness of less than 11 cm, which is unmatched by other display devices.
5, the power consumption is very small. Liquid crystal display devices, low power, low heat have always been praised by people, only 3W in standby mode.
6. The failure rate is low. Liquid crystal is the most stable and reliable display device at present. Due to the small amount of heat generated, the device is stable and will not cause malfunction due to excessive temperature rise of components.

Panel details:

Brand	LG Display	Model	LD550DUN-TMA1
Diagonal Size	55 inch	Type	a-Si TFT-LCD , LCM
Pixel Format	1920(RGB)×1080 [FHD]	Configuration	RGB Vertical Stripe
Active Area	1209.6(H)×680.4(V) mm	Outline Dim.	1210.51(H)×681.22(V) mm
Bezel Area	-	Treatment	Antiglare (Haze 3%), Hard coating (2H)
Luminance	700 cd/m² (Typ.)	Contrast Ratio	1200:1 (Typ.) (TM)
View Direction	Symmetry	Response Time	8 (Typ.)(G to G)
Viewing Angle	89/89/89/89 (Min.)(CR≥10)	Operating Mode	S-IPS, Normally Black, Transmissive
Support Color	1.06B 72% (CIE1931)	Light Source	WLED , 50K hours , With LED Driver
Spliced Seam	0.9 mm (active to active seam)	Designed For
Frame Rate	60Hz	Touch Panel	Without
Interface Type	51 pins LVDS (2 ch, 10-bit) , Connector
Power Supply	12.0V (Typ.)
Environment	Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
