    153'' Video Wall Touch Screen Frame Super Large Size For 3X2 49 Inch Wall Monitor

    Ask Lasest Price
    Brand Name : GENEVISION
    Model Number : MG-153
    Certification : CE, FCC, ROHS, CCC
    Price : USD1300-USD1400/SET
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 3000 set /month
    Delivery Time : 7 work days
    • Product Details
    • Company Profile

    153'' Video Wall Touch Screen Frame Super Large Size For 3X2 49 Inch Wall Monitor

    153inch Factory Price Video Wall Touch Screen Frame in Super Large Size for 3X2 49inch Wall Monitor


    Genevision provides IR multi touch screen overlay/frame, IR multi touch video wall, IR touch screen monitor and other OEM/ODM products such as interactive kiosk, inquiry machine, digital signage, smart whiteboard, touch table and the like.


    Driver-free, plug and play

    High anti-light interference capacity, working normally in the sunlight

    Shorter response time, single touch<16ms, dual touch<6ms

    The touch area can be assigned

    Compound hybrid matrix is applied, leading to a high fault-tolerant rate

    Many people can write at the same time with precise touch

    The software has got Microsoft drive certification, guaranteeing high security and stability

    Support fast failure location due to built-in hardware diagnosis function,

    Solid hardware, support bulk shipment

    Low power consumption with no need for external power supply


    TypeNameVideo wallTouch frame size(inch)
    MDT-85inch47inch video wall(Vertical*Horizontal)1*285"
    MDT-171inch2*4171"
    MDT-84inch46/49inch vidoe wall(Vertical*Horizontal)1*284"
    MDT-123inch1*3123"
    MDT-163inch1*4163"
    MDT-203inch1*5203"
    MDT-251inch1*6251"
    MDT-93inch2*293"
    MDT-129inch2*3129"
    MDT-168inch2*4168"
    MDT-139inch3*3139"
    MDT-175inch3*4175"
    MDT-213inch3*5213
    MDT-251inch3*6251
    MDT-184inch4*4184
    MDT-221inch4*5221
    MDT-259inch4*6259
    MDT-100inch55inch video wall(Vertical*Horizontal)1*2100"
    MDT-146inch1*3146"
    MDT-193inch1*4193
    MDT-110inch2*2110"
    MDT-153inch3*2153"
    MDT-199inch2*4199"
    MDT-245inch2*5245"
    MDT-293inch2*6293
    MDT-165inch3*3165"
    MDT-204inch3*4204"
    MDT-252inch3*5252
    MDT-298inch3*6298
    MDT-220inch4*4220
    MDT-263inch4*5263"
    MDT-351inch4*7351"
    MDT-397inch4*8397

    MechanicalParametersTouch methodAny opaque object, such as finger, pen, glove, etc.
    Touch timesUnlimited
    Touch active powerNo need
    SafetySelect different toughened glass according to safety grade
    NoiseNo noise
    Surface durabilityThe surface rigidity is same as glass, 5.0-7.0 OGN/M²
    ElectricalParametersOperation Voltage+5V DC, Allowed +4.75 to +5.25V
    Power modeUSB
    Power Consumption1W - 2.5W
    ESD protectionAir: ±8KV, Body: ±4KV
    InterfaceUSB 2.0
    Environmental ParametersTemperatureOperation: -20~60; Storage: -40~85
    Humidity10%~90%RH
    IP gradeIP65
    Light resistanceAmbient light resistance, work normally in the sunlight
    FunctionParametersTouch point2/4/6/10/16/32/64 points
    Resolution32768 x 32768
    Linearity tolerance1 mm
    Response timeFirst click<16ms, continuous click<6ms
    DriftingNo drifting
    Supported protocolsWin7, flash, TUIO, etc
    Operating systemsWindows 8/7/XP, MAC OS X, Linux, Android, etc
    Min. touch diameter5mm
    LuminousnessNo glass 100%, AR glass 92%, common toughened glass 90%
