55" 85" Android OPS Interactive Multi Touch Screen Whiteboard For Zoom Meeting

Ask Lasest Price
Brand Name :	GENEVISION
Model Number :	MAD-550
Certification :	CE, FCC, ROHS, CCC
Price :	USD587 / PC
Payment Terms :	L/C, T/T, Western Union
Supply Ability :	3000 set /month
Delivery Time :	10 working days

Add to Cart

Product Details
Company Profile

55" 85" Android OPS Interactive Multi Touch Screen Whiteboard For Zoom Meeting

55" 85" IFP Zoom Meeting Camera Microphone Android OPS Multi Touch Screen Inerative Flat Panel

Quick details of touch screen interactive flat panel :

1. Hotsale size is 55 inch, 65 inch, 75 inch and 85 inch.

2. 20 points multi touch screen.

3. With 8.0Mpx camera inbuilt.

4. With 8 array microphone inbuilt.

5. 2pc 10W larger power speaker, also support connect to external speaker and sound system.

6. AG glass in front.

7. 4K resolution, 3840*2160.

8. Android 9.0 system inbuilt, 3G+32G, support google play.

9. Can be with OPS Windows system.

10. Have CE, ROHS, CCC, RCM, FCC certificates.

Description of touch screen interactive flat panel :

More and more meeting room and office need the interactive flat panel for training and zoom internet meeting. Currently big screen like 65inch, 75inch and 85inch cost lower and lower than before, so the demand of touch screen smart boar is increasing day by day.

Our touch screen smart board has AG glass in front, so screen can be seen clearly from every viewing angle, has 20 points touch screen with IR touch technology, reliable touch screen design and fast touch speed.

4K resolution, 3840*2160. Has Android 8.0 system already, 3G+32G spec, also can be with OPS Windows system, system also can support 4K resolution.

Can be hang on the wall or with movable stand, has wheels on base, can be moved anywhere quite easily.

On the top center, camera and microphone can be inbuilt, which has 8.0MPX definition and 10Meter sound pickup distance.

Specification of touch screen interactive flat panel :

Active Display Area	1209*680mm	1428*803mm	1649*927mm	1872*1053mm
Aspect Ratio	16:9
Visual Angle	Horizontal178/Vertical178
Panel	Original BOE, LG, AUO, Innolux ect. A Level
Brightness	280-350cd/m2
Contract Ratio	1200:1		1400:1
Resolution Ratio	3840*2160
Color Components	8 bit/16.7 Million
Refresh rate	60HZ
Response Time	8ms
Power Consumption	120W	200W	270W	330W
Standby power consumption	≦0.5W
Glass	4mm thickness AG tempered glass
Touch screen spec	IR 20-point touch screen, resolution: 4096X4096, port: USB 2.0, response time: <8ms, scanning speed: 100Hz/sec, sensor speed: 125P/S, accuracy: ≦2mm
Speaker	8Ω 10W*2pc
Power Supply	Input:AC110-240V-50/60Hz
Color of Shell	Black
Life of Panel	60000Hours
Smart phone wireless screen sharing	Support, included, by APP or QR code
Dimension of Machine	125874683MM	1483.6905.688.7MM	1705.81030.5588.9MM	1951MM116989MM
Carton box packing	1367185892mm, G.W.: 31KG	16002051001.5MM, G.W.: 46KG	18462151180mm, G.W.: 69KG	20922151319mm, G.W.: 83KG
Photo formats	JPG,BMP,PNG ect, support Rotate / slide show / picture zoom in
Audio formats	MPEG1/2 layer I/II,AC-3(need customize),AAC-Lc,WMA…
Video formats	MPEG-2/4,AVS,H.264,H.265,TS,Realmedia…
OSD Language	English, Chinese
Working Temperature/ Hulmidity	-10℃-50℃ / 10%RH~90%RH
Storage Temperature/ Hulmidity	-20℃-60℃ / 10%RH~90%RH
Accessory	Wall hanger, expansion screw, touch pen, remote control
Front port	USB2.01, USB3.01	TOUCH1, HDMI in1, USB2.01, USB3.01
Android Mainboard Configuration
Chipset	MSD848(8386)
CPU	Cortex A732 A532 1.5GHz
RAM	DDR3 3G
Memory	32G
OS	Android 8.0, with bluetooth
SD card	Support MAX 128GB SD card
Input port	RJ451(side)HDMI2(side)TOUCH USB1(side)VGA1(side), AUDIO IN1(side) YPBPR1(side)AV1(side)TV1(side)
Output port	SPDIF1(side)Earphone1(bottom)
OPS Configuration
CPU	i7-8700
Memory	DDR4 16G
SSD	256G
OS	Windows10 Pro
Input Port	1LAN, 2USB3.0, 4USB2.0, 1MIC-IN
Output Port	1HDMI out, 1VGA out
8.0Mpx Camera Module Specification
Sensor	IMX317CQC-C
Sensor Lens Size	1/2.5 inch
Sensor Pixel array number	3864*2196
Data formats	YUY2Mjpg
Sensor pixel size	1.62μm(H)×1.62μm(V)
Dynamic range	Digital overlap HDR
Focusing	Fixed focus
Module Rate	Mjpg 3840*2160 @30fps
Voltage	5V
Max working current	220mA
USB Connector	USB2.0
Sensor power supply	Core = 1.2V±0.1V Analog = 2.8V±0.1V I/O = 1.8V±0.1V
Sensor output formats	RAW12/RAW10
Sensor input clock frequency	6 to 27 MHz
Sensor maximum image transfer	(3864x2196): 30 fps
Sensor image area	Diagonal 7.20 mm
Output video format	25921944, 19201080, 1280*720
Camera Lens Specification
Lens size	1/2.5 inch
Focus length	2.88mm
F/No.	2.7mm±5%
Field of View Angle (Diagonal)	100.6(D)/92.4(H)/61(V)±3%
Distortion	＜-0.1%
Image Quality	Center≥1200 LW/PH；Corner≥1000 LW/PH
Focusing Range	0.49m - ∞(AT=1.0m)
8 Array Microphone
Microphone type	Linear equidistant array microphone
No. of digital micropone	8
Signal to noise ratio	65db
Sensitivity	-38±1db
Pickup distace	10 meter
Sampling rate	48KHz
Function support	Echo cancellation Beamforming Environmental noise suppression Sound source location Listening function Omnidirectional microphone Dual talk AEC, supporting full duplex calls Remove the reverberation in the meeting room and maintain the degree of human voice restoration and sound recognition Automatic gain - AGC gentle high sound enhanced low sound - provides a consistent call experience
Number of sound pickup plates	2
Pickup size	135×6×1.6mm
Main board size	100×17×1mm
System support	Windows7/10; Android7.0 and above
Cable	FFC
Communiaton type	USB3.0
Power supply type	USB
Working voltage	USB 5V±5％
Average current	＜300mA

Application of touch screen interactive flat panel :

This touch screen smart board can be used in school, meeting room, exhibition center, office, also the smart interactive flat panel can be used in eudcation institutes.
