Office 8" IR Temperature Scanner Touch Screen Kiosk Fever Alarm
Camera Screening Thermoeter
8" EU Health Code Indentification Facial Recognition Thermal
Scanner SmartPass Management Access Control System
Quick points of facial recognition temperature detector with camera
:
1. Scan present health certificate QR code.
2. Local check indentification.
3. Display the visitor's information such as health QR code / body
temperature / mask wearing, if they are normal, the visitor can
pass through.
4. Give sound alarm when it scan health QR code anomaly / Abnormal
temperature / Non-wearing mask / Stranger etc.
5. 8" IPS panel, A level, 1280*800 resolution, with facial
recogntion camera, Binocular wide dynamic camera, 2.0Mpx, support
1: 1 face comparison.
6. QR code scanner inbuilt to scan EU health code and pass
recording.
7. Mask wearing, abnormal temprature alarm.
8. Door access control system software for free.
9. Can be used with hand sanitizer dispenser.
10. Has wall mountable bracket, height adjustable floor stand,
desktop stand.
11. To be used in office, exhibition center, airport, subway
station, bus station, cinema etc.
Specification of touch screen face scan thermometer :
| Resolution | 1280*800 IPS panel |
| Display area | 107.64(W)×172.224(H) mm |
| Brightness | 200cd/m2 |
| Number of Color | 16.7M |
| Response time | 8 (ms) approximately |
| Contrast | 800:1 |
| View angle | 170°/170°(H/V) |
| Life Time | > 50000 (hours) |
| Power Supply | DC12V (±10%) |
| Power Consumption | 14W |
| Camera | 2.0Mpx, Binocular wide dynamic camera |
| Focus distance | 50-150cm |
| White balance | Automatic |
| LED flash | LED and dual IR LED light compensation |
| Speaker | 2.5W/4R |
| Face recognition | Support several face detection together |
| Face recording database | 30,000 at most |
| 1: N face recognition | Suport |
| 1: 1 face comparison | Suport |
| Stranger detection | Suport |
| Identify distance configuration | Support |
| UI interface configuration | Support |
| Upgrade remotely | Support |
| Display interface | Interfaces include device management, personnel / photo management,
record query, etc. |
| Deployment model | Support public cloud deployment, privatized deployment, LAN use,
stand-alone use |
| Temperature detection | Support |
| Temperature sensor brand | Heiman or Omron |
| Temperature detection distance | 1 meter (optimal distance 0.5 meter) |
| Temperature measurement range | ≤ ±0.5℃ |
| Testing range | 10℃~42℃ |
| Thermal field of view | 32 X 32℃ |
| Visitors' temperature is normal and released directly | Support |
| Abnormal temperature alarm | Support (temperature alarm value can be set) |
| Waterproof | NO |
| Installation | Gate machine, height can be adjusted |
| Photo Formats | JPEG ,BMP ,GIF ,PNG |
| Audio Formats | MP3,WAV,WMA |
| Video Format | MP4,AVI,DIVX,XVID,VOB,DAT,MPG,MPEG,RM,RMVB,MKV,MOV,HDMOV,M4V |
| Shell Material | Aluminum+Metal |
| Carton dimension | 8pc/carton, 710*450*250mm, G.W.: 17kg |
| Touch Type | Optional |
| Scanner | Can be inbuilt to scan EUDCC / EU Health QR code |
| Normal Working Temperature | 0℃~60℃ |
| Normal Storage Temperature | -20℃~60℃ |
| Packing list | Machine * 1, power adapter * 1, manual * 1, certificate of
conformity * 1 |
| OSD Language | English, Chinese, French, German, Italian, Spanish,Arabic etc. |
| Support 27 Language broadcast | Simplified Chinese, traditional Chinese, English, Italian, Polish,
German, Russian, Thai, French, Arabic, Vietnamese, Czech, Romanian,
Japanese, Kazakh, Hebrew, Slovak, Netherlands,Turkish, Lithuanian,
Greek, Portuguese [Portugal], Portuguese [Brazil], Ukrainian,
Spanish, Indonesian, Korean, etc. |
| CPU | RK3288 Quadcore Cortex-A17 1.8GHz |
| RAM | DDR3 2G |
| Memory | 8G |
| Internet connetcion | Wifi, RJ45 |
| System | Android7.1 |
| USB port | OTG*1, USB HOST*1 |
| RS232 | 1 |
| Relay output | 1 signal output for door openning |
| Wiggins interface | 26/34 output*1, 26/34 input |
| Upgrade | Support Uboot upgrade |
| 1. Use 8Inch IPS LCD screen with full viewing angle |
| 2. Industrial grade, waterproof, dust free design, high end, steady
and reliable quality |
| 3. Support face recording database of 30,000. 1:1 face matching
rate at more than 99.7%, 1:N face matching rate at more than
96.7%@0.1% FAR( False Accept Rate), Bio-assay detection accuracy
rate at 98.3%@0.1% FAR, face detection and pass needs less than 1s |
| 4. Support face accurate detection and matching when people wearing
mask |
| 5. Use industrial grade two-eye dynammic camera, with IR technology
for night use, LED light compensation technology |
| 6. Has Rockchip RK3288 Quad-core CPU, RK3399 Six-core CPU, Qualcomm
MSM8953 Octa-core processor on option |
| 7. Support human body temperature detection, temperature display,
long distance detection of more then 1M, 0.2℃ error range, support automatic alarm for abnormal temperature, fast
detection speed at 1s, real time temperature detection data output |
| 8. Support other components embeded like ID card reader, finger
print, IC NFC, QR code scanner |
| 9. Support various API connection for system, APP offline, APP+
background network, support secondary development |
| 10. With QR code scanner to scan EUDCC / EU Health QR Code, dispay information on screen, the relevant information will only
be temporarily checked and not saved to the local area. |
| 11. Privacy protection features: 1. Personnel can be set to display customized pictures, 2. Can
independently set stranger record retention time, support automatic
deletion of stranger records, 3. Support stranger mode, that is,
only measure the temperature after identifying strangers without
record traffic data. |
Description of IR thermometer temperature screening scanner :
This 8 Inch facial recogntion thermometer temperature screening
camera has greately help to control the epidemic all over the
world, comparing to the spec in the year of 2020, we have added QR
code scanner for the hardware, which can scan EUDCC or also called
EU health code in EU countries, also it has privacy protection
function, which means people pass record can only be checked
temporarily but not saved in local area, also with IC card reader
function, user won't need to upload their pictures into the 8" face
scan thermometer, can independently set stranger record retention
time, support automatic deletion of stranger records, support
stranger mode, that is, only measure the temperature after
identifying strangers without record traffic data.
The SmartPass system will be provided for free as always, besides,
with the API documents, it support second development, also some
customer has dveloped their own gate access control system
accordingly the local law also. So it support various API
connection for system, APP offline, APP+ background network,
support secondary development.
The abnormal temperature alarm thermo thermal scanner also can work
off line, can be used in office and community, employee attendance
information, check in and check out time can be saved in a local
computer for personnel department to check if they come to work in
normal temperature, our gate access control system can be connected
to swing or replay gate, it won't open the door for abnormal
temperature or strangers. For an employee in a company, they also
can check in and check out with staff IC or ID card rather than
save their peronal pictures in the 8" body temperature measuring
device system.
Support various installation like hang on the wall, stand on the
floor or on the table, floor stand height can be customized or
adjustable, connect to the relay gate and so on.
They are ready in stock with fast delivery time 5-7 days.
Application of door access control system facial scan thermal
scanner :
This 8" thermal scanner access control thermometer can be widely
used in hospital, school, airport, subway station and train
station, can work together with passage gate entrance access
controller in community, office building, hotel, scenic spot,
transportation junction or other public service area etc.
