65" Curved IR Touch Screen Digital Signage LCD Video Wall in 4K
Resolution
Quick details of seamless LCD video wall advertising player :
1. 65inch BOE original panel LCD video wall, A level.
2. 3.5mm narrow bezel.
3. 500nits high brightness.
4. With 10 fingers IR touch frame, to be attached onto a piece of
tempered glass in front of video wall monitor.
5. 4K resolution with 3840*2160 resolution.
6. Can be with DP daisy chain port, also has HDMI, DVI, VGA and
RS232.
7. Can be hang on the wall with pop-up bracket, also can be
installed on floorstanding bracket with front maitenance bracket,
cabinet model with metal piece.
9. This is ODM project, curved shape LCD TV wall screen standing on
the floor.
10. multi line parallel processing with powerful full processing
CPU.
11. RS232 serial port has remote control function, support two
RS232 loop outs.
12. Narrow border full metal frame design.
13. Fully silent industrial fan with automatic temperature switch.
14. With noise reduction, filtering and deinterlacing design.
15. With energy saving, environment protection, no radiation,
support 7*24 hour uninterrupted work, adapt to variety of working
environment that need to be turned on for along time.
16. Uniform brightness, stable image, no ficker, no distortion.
17. To be used in commercial institutions, large shopping malls,
specialty stores, franchise stores, hypermarkets, star hotels,
restaurants, travel agencies, drug store, exihibition centers etc.
Description of narrow bezel lcd advertising wall display :
Genevision is professional LCD video wall supplier for more than 17
years, we're one-stop provider has screens and all components in
the package, customer just need to take them from the wooden box
and start install when they got our shipment.
4K daisy chain with DP port is a common solution for LCD video wall
monitor project, no matter how many screens you want to put
together, it's ok if the wall is strong enough, like 2*2 or 3*3 or
7*8 etc. Comparing to traditional screen with 1pc RS232 in and 2pc RS232
out, DP daisy chain make the cable connection and installation much
easier, besides, no need screen splitter or matrix anymore with
this solution, it's just cost higher than standard solution.
Support full screen displaying and each screen display different
contents like video and picture.
We can attach IR touch from in front of 10mm tempered glass to make
LCD video wall tangible, suggest customer buy glass locally as it's
dangerous to ship from China, if too many screen monitor to be
installed together and the area is too large, we suggest cut glass
into several piece and attach them together one by one locally,
it's enough to attach touch frame onto the glass with glue. This
solution also support wall mountable installation, inbuilt into a
hole in the wall, floorstanding bracket or floorstanding cabinet.
Pop-up bracket is quite normal for LCD video wall project, which
can make maintenance and installation much easier, if hang on the
wall, each screen need one piece front-maintenace bracket, it
support VESA mounting, also the installation level can be
adjustable.
Specification of ultra narrow bezel LCD TV wall monitor :
| Specification | MG-650
| Panel Size | 65"LED |
| Panel brand | Original BOE A level |
| Aspect Ratio | 16:9 |
| Visual Angle | Horizontal 178/Vertical178 |
| Brightness | 500cd/sqm |
| Bezel | 3.5 mm |
| Back light | LED backlight |
| Contract Ratio | 1200:1 |
| Resolution Ratio | 3840*2160 |
| Color Components | 16.7M |
| Response Time | 8ms |
| Power Consumption | 120W/150W |
| Standby power consumption | 10W |
| Power Supply | Input:AC110-220V-50/60Hz |
| Life of Panel | 60000Hours |
| Panel Display Area | 1428.48(W)×803.52(H) mm |
| Outline Dimension | 1432.58(W)×807.62(H)×118.5mm |
| Port | Input: *1,VGA*1,DVI*1,AV*2,RS-232*1,Output: AV*1,RS-232*2 |
| VGA/DVI Resolution Ratio | 640*480,800*600,1024*768,1280*1024,1600*1200,1920*1080 |
| Resolution Ratio | 480I,480P,576I,720P,1080I,1080P |
| Split Screen/PIP Mode | Two signals image or PIP |
| Splice Function | Multiscreen Splice Function(image processing Function) |
| Carton Packing | 2pc/carton, carton size: 135*34*81cm, G.W.: 58kg |
| Wooden box packing | 7pc/wooden box, wooden box size: 140*128*98cm, G.W.:281kg |
| Bracket carton packing(for 7pc system) | 146*34*25cm, G.W.: 33kg |
Also, we have other brand of TV advertising LCD video wall as below
for your option :
| MD-DV460FHMNV0 | DV460FHM-NV0 | BOE | | | 500nits | 46inch 3.5MM |
| MD-DV490FHMNV4 | DV490FHM-NV4 | BOE | | | 500nits | 49inch 3.5MM |
| MD-DV550FHMNV8 | DV550FHM-NV8 | BOE | | | 500nits | 55inch 3.5MM |
| MD-DV550FHMNVD | DV550FHM-NVD | BOE | | | 500nits | 55inch 0.88MM |
| MD-DV650QUMNV0 | DV650QUM-NV0 | BOE | | | 500nits | 65inch 3.5MM 4K |
| MD-DV550FHZNVF | DV550FHM-NVF | BOE | | | 500nits | 55inch 3.5MM |
| MD-DV550FHMNV9 | DV550FHM-NV9 | BOE | | | 500nits | 55inch 1.7MM |
| MD-DV460FHMNV3 | DV460FHM-NV3 | BOE | | | 500nits | 46inch 1.7MM |
| MD-DV460FHMNV2 | DV460FHM-NV2 | BOE | | | 500nits | 46inch 0.88MM |
| | | | | | |
| MD-LD490DUNZMA1 | LD490DUN-ZMA1 | LG | | | 500nits | 49inch 3.5MM |
| MD-LD550DUNTGB5 | LD550DUN-TGB5 | LG | | | 500nits | 55inch 3.5MM |
| MD-LD550DUNTHB8 | LD550DUN-THB8 | LG | | | 500nits | 55inch 1.8MM |
| MD-LD550DUNTMA2 | LD550DUN-TMA2 | LG | | | 500nits | 55inch 0.88MM |
| MD-LD550DUNTHA8 | LD550DUN-THA8 | LG | | | 700nits | 55inch 1.8MM |
| MD-LD550DUNTMA3 | LD550DUN-TMA3 | LG | | | 700nits | 55inch 0.88MM |
| | | | | | |
| MD-SS550HJ1S02 | SS550HJ1-S02 | Innolux | | | 500nits | 55inch 3.5MM |
| MD-MG5461B011 | MG5461B01-1 | | | | 500nits | 55inch 3.5MM |
| MD-P550HVN08.2 | P550HVN08.2 | AUO | | | 500nits | 46inch 1.8MM |
Application of TV studio splicing screen LCD screen wall :
LCD screen wall can be used in TV studio, Exbition and Office, also
indoor LCD wall screen can be applied in start hotel, Library,
Museum and Cinema.
