    Interactive Capacitive Touch Foil Film PCAP Touch Screen Kiosk Transparent Nano Touch Wall

    Ask Lasest Price
    Brand Name : Genevision
    Model Number : MGF-320 or other
    Certification : CCC
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 10000 pcs per month
    Delivery Time : 5 working days
    • Product Details
    • Company Profile

    Interactive Capacitive Touch Foil Film PCAP Touch Screen Kiosk Transparent Nano Touch Wall

    32" 42" 43" 55" 65" 85" 100"110" transparent Nano touch wall,Interactive Capacitive PCAP touch foil film for Window shop


    Features & advantage:
    1.Stable quality,9 years life time.
    2.Zero pressure and precise touch,fast response.
    3. Optional size:from 17" to 100"
    4.Water-proof, Ultraviolet-proof, Vandal resistant,easy clean.
    5.Suitable for different environment of indoor and outdoor.
    6.Flexible,could be used in innovative design and special construction .
    7.Fashionable and beautiful appearance,frameless,transparent, ultrathin design.
    8.The same technology of projected capacitive touch as IPAD,maximum supports 100 points now .
    9.Work through galss maximum thickness of 12mm .

    Specification:

    Available size42-84 inchTouch points10 points
    SeriesME-MiniTouch deviation≤0.5mm
    The number of sensors

    TX70 RX142(≤55inch)

    TX80 RX142(>55inch)

    Scanning speed10ms /frame
    Energy consumption2WDrive TypeDrive Free
    Arm RejectYesCustomnot support custom
    Point report Rate>100Film thickness≤100um
    Light transmission rateAbove 93%Supply voltage5V USB
    TransmissionUSB2.0Warranty1 Year
    Program-levelKernel-level low-level driveTechnical certificationCE,ilac-MRA,CNAS,CAL,CMA
    Ambient temperature-20℃ to +70℃Ambient lightnessWhole angle of the anti-glare
    Touch supportClick, drag, zoom, rotateSensing distance≤20mm( glass thickness )
    Calibration modeSoftware calibrationProgram typeAndriod,Linux,Mac,Windows7/8/8.1/10(see note)
    Transmission distance≤50m ( plus USB signal amplifier, etc )Safety distance2mm( refers to the distance between the LCD screen and the film)
    Packing List1 * touch film circuit/ control board * 1 /USB cable * 1

    Tag:Capacitive touch screen foil,Nano touch foil,touch foil film,multi touch screen film,transparent interactive touch foil
