Automatic Interactive Digital Signage , double lcd Kiosk Signage
Description:
1,Adopt hardened metal shell,antistatic,preventing magnetic strong
interference.
2, With 3mm thickness tempered glass as protection layer against
the surface of LCD screen.
3,Adopt newest A＋LCD screen,with high contrast ration,high
brightness,last longer and work better.
4,Support SD card or USB port at one player; it is optional for VGA
Port, S-video port and port.
Compatible all formats of high definition video signal and standard
definition video signal input(,YPbPr,
VGA,CVBS*2)and output(AV).
5,Safely locking system function to avoid flash memory card and
advertising playing contents being taken
away, also can be protected by password.
6, With USB update feature; support functions between the card and
card copying files (such as CF card to
SD card,or SD to CF card etc.); support U-copy, conveniently and
quickly updating target content, more
details please visit user manual.
7,Playing advertising program automatically and circular; support
media format: JPEG (JPG), MP3, AVI,
MPEG1, MPEG2, MPEG4, VOB and DIVX (5.0/6.0).
8,Playlists support functions, can set different folders, copy all
target files to those different folders, system
would default to play your target file one by one.
9,Capable of setting rolling caption on the screen, playing rolling
caption in the advertisement program.
10,Build-in clock and calendar function in the system of player.
11,Automatically turn up or down the volume of ad media player
after finished the period of time setup to
machine according to your requirements.Support 5 groups of auto
power-on/off timer, able to set those
5 groups of time one day and 7 days in one week.
12,Support 1080P Full HD Video and picture.
13,with scrolling marquee and angle icon display for any interval
and segment quantity.
14,Automatic restart and shutdown periodically.
15,Support playlist function and slides showing automatically.
16,Adopt an external power adapter to supply power,more safe and
reliable.
17,Automatic recognize PAL/NTSC video display
18,Support key operation and IR remote control.
19,Physical resolution up to 1920*1080,compatible below
resolution.automatically adjust to the best place.
20,The scientific Golden Angle Design is adopted for the body,
super-thin and light machine body.
Applications:
Business Organizations | supermarket, large-scale shopping malls, exclusive agency, chain
shops, large-scale sales, star-rated hotels, restaurants, travel
agencies, pharmacy. |
Financial Organizations | Banks, negotiable securities, funds, insurance companies,
pawnshops; Non-profit Organizations: Telecommunications, post offices,
hospital, schools; |
Public Places | subway, airports, stations, gas stations, toll stations,
bookstores, parks, exhibition halls, stadiums, museums, convention
centers, ticket agencies, HR market, lottery centers; Real Estate
Property: Apartments, villas, offices, commercial buildings, model
rooms, property brokers; |
Entertainments | Movie theaters, fitness halls, country clubs, clubs, massage rooms,
bars, cafes, Internet bars, beauty shops, golf course |
Specifications:
Model No. | MAD-D420 |
The material of machine body | Aluminium profile,3MMtoughened glass |
Certification | CCC,RoHS,CE |
Interface | USB |
Guarantee | 1 year |
Speaker | 10Wx2 |
Storage Medium | Flash memory card(2gb to 36gb for the capacity) |
Video formats | MP4(AVI:DIVX/XVID),MPG2(DVD:VOB/MPG2), MPEG1 (VCD: DAT/MPG1) |
Audio formats | MP3 |
Photo formats | JPG |
Audio output | stereo L/R, 5W*2, 8Ω |
Storage Temp. | -7 to 65 Celsius degree |
Normal Working Temp. | -5 to 65 Celsius degree |
Language | The default is Chinese and English,others need to be confirmed |
Power supply | AC 110V - 240V, 50/60HZ |
LCD display specification |
The size of screen | 42 inch |
Ratio | 16:9 |
Display area | 930mm(H) x 525mm(V) |
Dot Pitch | 0.484mm(H) x 0.484mm(W) |
Max Resolution | 1920x 1080 |
Number of colors | 16.7M |
Brightness | 600cd/㎡ |
Response Time | 8s |
Contrast | 4000:１ |
Viewing angle | 89°/89°/89°/89°(Min.)(CR≥10)(L/R/U/D) |
Using Life | 50000 hours |
Accessory |
Standard accessory | AC power line |
Remote Controller |
Base |
Warranty card |
Flash memory card |
Security Keys |
User Manual |
Competitive Advantage:
A stand-alone ad player with black full toughened glass to protect
the LCD Panel,also with decorative screws to make it perfect and
luxury.For the full-toughened glass, we adopt the silk-screen
technology for better quality and better appearance.This player is
also designed with wall mounted board for mounting function,and
also with VESA holes for your own bracket.
